PRODUCTS
LAYERS – We supply boards from 2 layers to 24 layers ,
Plated Through Hole
Single and Double sided conventional boards.
Flexibles (1 , 2 and 4 layer) plus flex rigid.
LAMINATES – Fr4, Fr2,CEM1 – 0.4mm to 6.1mm
BASE COPPER – 17.5um, 35um, 70um and 105um
ELECTRONIC DATA – Gerber 274X preferred.
HOLE SIZES – Min Drill 0.20mm , max drill 6..4mm, min slot width 0.6mm
TOLERANCES – Drill +/- 0.10mm
FINISHES – LF HASL, IMM SILVER, ENIG, OSP, TIN/LEAD SOLDER.
QUALITY
All suppliers are ROHS compliant, and have ISO 1400, ISO 9001, TS16949 and adhere to IPC specification unless otherwise stated.
